| 效能 | 輸出信噪比(A-Weighted):
118 dB
輸入信噪比(A-Weighted):
118 dB
輸出THD+N at 1kHz:
0.00039% (-108dB) for Front channel of Line-out
輸入THD+N at 1kHz:
0.0003% (-110dB) for Line-in
頻率響應(-3dB, 24-bit/96kHz input):
<10Hz to 46KHz
輸出/輸入全面電壓:
2 Vrms (5.65 Vp-p)
|
| Bus Compatibility | PCI Express:
PCI Express Rev.1.0a specification compatible.
Maximum full 2.5Gbps bandwidth per direction and optimized latency for high-definition audio processing.
Compatible with X1, X4, X8, X1 6 PCI Express slots.
|
| 晶片 | Audio Processor:
ASUS AV100 High-Definition Sound Processor (Max. 192kHz/24bit))
High Fidelity Headphone Amplifier:
Texas Instruments 6120A2*1 (120dB SNR, -117dB THD+N @ Vcc+-12V, RL=600Ω, f=1kHz) 24-bit D-A Converter of Digital Sources:
Texas Instruments PCM1796*1 for Front-Out (123dB SNR, Max. 192kHz/24bit); Cirrus-Logic CS4362A*1 for other 6 channels (114dB SNR, Max.192kHz/24bit)
24-bit A-D Converter for Analog Inputs:
Cirrus-Logic CS5381 x 1 (120dB SNR, Max. 192kHz/24bit)
|
| 採樣率與解析度 | 類比播放採樣率與解析度:
44.1K/48K/96K/192KHz @ 16/24bit
類比錄音放採樣率與解析度:
44.1K/48K/96K/192KHz @ 16/24bit
S/PDIF數位輸出:
44.1K/48K/96K/192KHz @ 16/24bit, Dolby Digital
ASIO 2.0 驅動支援:
44.1K/48K/96K/192KHz @16/24bit with very low latency |
| I/O 連結孔 | Front-Panel Header
Shared by Headphone out / 2 channels out / Microphone in
類比輸出插孔:
6.30mm jack*1 (Headphone out); 7.1ch analog output (via bundled audio splitter cable)
類比輸入插孔::
6.30mm jack *1 (Shared by Line-In/Mic-In)
其他類比線材輸入 (提供給 CD-IN/TV Tuner):
Aux-In (4-pin header on the card)
數位S/PDIF輸出:
High-bandwidth Coaxial/TOS-Link combo port supports 192KHz/24bit
|
| 執行特色 | DS3D GX2.0:
GX 2.5 supports EAX gaming sound effects and Di rectSound 3D hardware enhanced functions for more games on Windows XP/Vista/7. (DirectX/DirectSound 3D compatible)
作業系統:
Windows Vista/XP(32/64bit)/MCE2005
Dolby®杜比音效技術:
Dolby® Digital Live, Dolby® Headphone, Dolby® Virtual Speaker, Dolby® Pro-Logic II
Smart Volume Normalizer™:
Normalizes the volume of all audio sources into a constant level and also enhances your 3D sound listening range and advantages in gaming
Xear 3D™ Virtual Speaker Shifter:
Virtual 7.1 speaker positioning
FlexBass™:
Professional Bass Management/Enhancement system
其他效果:
10-band Equalizer/27 Environment Effects
3D聲音引擎/APIs:
DirectSound3D® GX 2.0 & 1.0, EAX®2.0&1.0, DirectSound® HW, DirectSound SW, OpenAL generic modes, 128 3D sounds processing capability
|
| 配件 | 1 x S/PDIF optical adaptors
1 Others
1 x Driver CD
1 x Quick Start Guide
|
| Size | 111.15mm 178.06mm x |
